Product Specification
Brand
BOSCH
Local Manufacture Warranty
6 MONTH
Product Description
✔Powerful impact system with 2.0 J, 3 mode hammer for versatile usage
✔Reduced maintenance due to brushless motor and increased runtime per battery charge
✔No sparks and less heat generation during use thanks to brushless motor
TECHINICAL DATA
| Battery voltage | 18.0 V |
| Max. impact energy | 2 J |
| Weight excl. battery | 2.3 kg |
| Impact rate at rated speed | 0 – 5,100 bpm |
| Rated speed | 0 – 1,800 rpm |
| Tool holder | SDS plus |
Drilling range | |
|---|---|
| Drilling dia. in concrete with hammer drill bits | 4 – 20 mm |
| Opt. app. range in concrete with hammer drill bits | 6 – 10 mm |
| Max. drilling diameter in metal | 13 mm |
| Max. drilling diameter in wood | 30 mm |
Total vibration values (Hammer drilling in concrete) | |
|---|---|
| Vibration emission value ah | 10 m/s² |
| Uncertainty K | 1.5 m/s² |
Noise/vibration information | |
|---|---|
| Sound pressure level | 90 dB(A) |
| Sound power level | 101 dB(A) |
| Uncertainty K | 3 dB |
Hammer drilling in concrete | |
|---|---|
| Vibration emission value ah | 10 m/s² |
| Uncertainty K | 1.5 m/s² |
Chiselling | |
|---|---|
| Vibration emission value ah | 7 m/s² |
| Uncertainty K | 1.5 m/s² |
The A-rated noise level of the power tool is typically as follows: Sound pressure level 90 dB(A); Sound power level 101 dB(A). Uncertainty K= 3 dB.
